LVA-273PN-DG+

Die Gain Block, 0.01 - 26.5 GHz, 50Ω

LVA-273PN-DG+

Data, Drawings & Downloads

Datasheet
Data
Graphs
Full Data
Enquire about this product

FEATURES

• Wide Bandwidth 0.01 to 26.5GHz
• Ultra-low Phase Noise Typ. -172dBc/Hz @ 10kHz Offset
• Output P1dB Typ. +18dBm
• Output IP3 Typ. +28dBm
• Supply Voltage: +5V and 85mA

PRODUCT OVERVIEW

Mini-Circuits LVA-273PN-DG+ is an ultra-low phase noise distributed MMIC amplifier die fabricated on a GaAs HBT process technology. Operating from 0.01 to 26.5GHz, this amplifier features high dynamic range and ultra-low phase noise along with 18dB gain, +18dBm P1dB, +28dBm OIP3, and 3.7dB noise figure. The LVA-273PN-DG+ is ideal for use with low noise signal sources and highly sensitive transceiver signal chains for commercial, industrial, and defense applications.
